Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of grain oriented electrical steels in China. Welcome to wholesale customized grain oriented electrical steels at low price from our factory. If you have any enquiry about free sample and cheap products, please feel free to email us.
GNEE produces GOES in thicknesses of 0.001″ (0.025mm), 0.002″ (0.05mm), 0.004″ (0.10mm) and 0.006″ (0.15mm) and provides slit widths from 0.02″ (5.08mm) to 17.0″ (431.8mm), depending on gauge.
Our grain oriented silicon steel material meets IEC 60404-8-8.
GOES thin gauge strip can be shipped bare or with an inorganic coating, capable of surviving 920°C annealing temperature (C-5 IEEE class).
GOES APPLICATIONS
GNEE's GOES materials are typically used in power, instrument and current transformers, as well as cores for High-voltage direct current (HVDC) transmission systems. Arnold's GOES materials are commonly produced in 0.006″ (0.15mm) and 0.004″ (0.10mm) thicknesses for frequencies below 1 KHz, and 0.001″ (0.025mm) and 0.002″ (0.05mm) for higher frequencies.
For higher frequency applications, using thinner materials reduces the negative effects of core losses due to eddy currents. By keeping core loss to a minimum, heat buildup is minimized.
GNEE's GOES is available in the following gauges and dimensions:
| GAUGE | SLIT WIDTH MINIMUM | SLIT WIDTH MAXIMUM |
|---|---|---|
|
0.001″ (0.025mm) 0.002″ (0.05mm) 0.004″ (0.10mm) |
0.20″ (5.08mm) |
All gauges: 17.0″ (431.8mm) as rolled 16.5″ (419.1mm) with a slit edge |
|
0.006″ (0.15mm) |
0.20″ (5.08mm) |
17.5″ (444.5mm) as rolled 17.0″ (431.8mm) with a slit edge |
