I believe that many friends now want to know more about the complete specification table of galvanized sheet thickness, so today the editor of Xiaohao has collected some knowledge about the complete specification table of galvanized sheet thickness to share with you.
The thinnest galvanized sheet thickness is: 0.35mm.
Galvanized sheet thickness specifications include: 0.35㎜, 0.40㎜, and 0.45㎜.
The size specifications of galvanized sheets include: 710x1420, 750×750, 750x1500, 750x1800, 800x800, 800x1200, 800x1600, 850x1700, 900x900, 900x1800, 900x2000, 1000x2000, etc.
Galvanized steel sheet index (unit: g/m2)
JISG3302 code Z12 Z18 Z22 Z25 Z27 Z35 Z43 Z50 Z60
Galvanizing amount 120 180 220 250 270 350 430 500 600
ASTMA525 code A40 A60 G60 G90 G115 G140 G165 G185 G210
Galvanizing amount 122 183 183 275 351 427 503 564 640
①Performance indicators: Generally speaking, only galvanized sheets for structural use, drawing use and deep drawing use have tensile performance requirements. Among them, galvanized sheets for structural use require yield point, tensile strength and elongation, etc.; for tensile use, only elongation is required.
②Test method: The same as the general thin steel plate test method.
