Large Diameter Seamless Stainless Steel Pipe

Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of large diameter seamless stainless steel pipe in China. Welcome to wholesale customized large diameter seamless stainless steel pipe at low price from our factory. If you have any enquiry about free sample and cheap products, please feel free to email us.



Large Diameter Seamless Stainless Steel Pipe video

GNEE STEEL Stainless Steel offers a variety of welded and seamless large diameter stainless steel pipe, including thick and thin wall pipe, available in standard and custom sizes up to 40 inches in outer diameter and 70 millimeters in wall thickness. Large diameter pipe is manufactured to most ASTM and international standards and specifications.

Generally, stainless steel grades include 304, 304L, and 316/316L. Other grades that meet standards are also available. Large-diameter stainless steel pipes have good corrosion resistance and enhanced adhesion and can be used in various environments. Large-diameter pipes undergo in-house pickling and passivation, in-house hydrostatic testing, and in-house X-ray testing to ensure quality.







You can get a better understanding of the Large Diameter Seamless Stainless Steel Pipe here.

Large-diameter seamless steel pipe is a kind of seamless steel pipe, including hot-rolled large-diameter seamless steel pipe and heat-enlarged diameter seamless steel pipe.
China's large-diameter seamless steel pipes are mainly produced using hot-rolled large-diameter seamless steel pipes and heat-expanded seamless steel pipes. The maximum specifications of heat-expanded seamless steel pipes are 325mm-1220mm and the maximum thickness is 200mm. Thermal-expanded seamless steel pipes can produce non-woven fabrics. The size of the national standard, thermal expansion seamless pipe is often referred to as thermal expansion, a rough pipe finishing process in which steel pipes with relatively low density but strong shrinkage are enlarged by cross-rolling or drawing methods to expand the diameter of the pipe. Thickening steel pipes in a short period of time can produce non-standard and special types of seamless pipes with low cost and high production efficiency. This is the development trend in the field of international pipe rolling.
GB5310 (seamless steel pipe for high-pressure boilers) stipulates that steel pipes with an outer diameter greater than or equal to 76mm and a wall thickness ≥14mm should be subjected to a Charpy V-type longitudinal impact test at 20°C; the average impact energy of the three samples should not be low At 40J, the impact energy of a sample is allowed to be lower than the average value, but not lower than 70% of the average value. For steel pipes with an outer diameter greater than 219.1mm and a wall thickness ≥25mm, transverse mechanical property tests can be used instead of longitudinal mechanical property tests. Carry out Charpy V-type lateral impact test at 20°C. It is more convenient to conduct lateral mechanical property test on large-diameter pipes.

Large Diameter Seamless Stainless Steel Pipe



Grade		Mechanical propcrites
		Tensile strength	Yied strength	Elongation	Hardness
		KSi(MPa)	KSi(MPa)	%	HRB
ASTM	TP304	≤75(515)	≤30(205)	≤35	≤90
	TP304L	≤70(483)	≤25(170)	≤35	≤90
	TP316	≤75(515)	≤30(205)	≤35	≤90
	TP316L	≤70(483)	≤25(170)	≤35	≤90
JIS	SUS304	≤75(520)	≤30(206)	≤35	≤90
	SUS304L	≤70(481)	≤25(177)	≤35	≤90
	SUS316	≤75(520)	≤30(206)	≤35	≤90
	SUS316L	≤70(481)	≤25(177)	≤35	≤90
GB	0Crl8Ni9	≤75(520)	≤30(210)	≤35	≤90
	00Crl9Nil0	≤70(480)	≤25(180)	≤35	≤90
	0Crl7Nil2Mo2	≤75(520)	≤30(210)	≤35	≤90
	00Crl7Nil4Mo2	≤70(480)	≤25(180)	≤35	≤90
EN10217-7	1.4301	(500-700)	≤(195)	>40b	≤90
	1.4307	(470-670)	≤(180)	>40b	≤90
	1.4401	(510-710)	≤(205)	>40b	≤90
	1.4404	(490-690)	≤(190)	>40b	≤90

Large Diameter Seamless Stainless Steel Pipe



You can learn more about Gnee here.

Foreign customers visit

GNEE Steel Group Steel Precision Tube Product Warranty & Shipping



Q: Can you send samples?
A: Of course, we can send samples to all over the world, our samples are free, but customers need to bear the express cost.

Q: What shipping ports are there?
A: Generally, we ship from Tianjin Port, you can choose other ports according to your needs.

Q: What product information do I need to provide?
A: You need to provide the grade, width, thickness, coating and tonnage you need to purchase.

Q:About Large Diameter Seamless Stainless Steel Pipe product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.
