SGC440 steel Coil/strip/sheet surface treatment:
C (Chromate treatment),NC(Non Chromate treatment), O (oiling), X (unoiling) NP(Phosphating treatment of non chromate), P(Phosphated), M(Untreated)
SGC440 steel Coil/strip/sheet coating mass:
Pure Zinc coating: Z06 (60g), Z08(80g), Z10(100g), Z12(120g),Z14(140g),Z18(180g), Z20(200g), Z22(220g), Z25(250g), Z27(270g), Z35(350g), Z37(370g), Z45(450g), Z60(450g)
Alloy Zinc+Fe: F04(40g), F06(60g), F08(80g), F10(10g0), F12(120g), F18(180g)
SGC440 steel Coil/strip/sheet coating: Z ( Pure Zinc), ZF( Z+Fe alloy)
JIS G 3302 SGC440 steel suitable size: Thickness 0.25mm-3.2mm
SGC440 steel chemical composition % :
| Grade | C max | Mn max | P max | S max |
| SGC440 | 0.25 | 2.0 | 0.20 | 0.05 |
SGC440 steel steel Mechanical properties
| Grade | Yield Strength MPa | Tensile strength MPa | Elongation % min | |||||
| 0.25-≤0.40mm | 0.40-≤0.60mm | 0.60-≤1.0mm | 1.0-≤1.6mm | 1.6-≤2.5mm | Above 2.5mm | |||
| SGC440 | 335 min | 440 min | 18 | 18 | 18 | 18 | 18 | 18 |
GNEE STEEL have more than 2000 tons SGC440 steel stock source each month. We can meet our customer's most of quantity and technical request. Based on these stock source, our advantage industry spread into steel process like : cutting(on width and length), drawing, repacking, and so on.
