DC01 steel (1.0330 material) is a European standard cold-rolled high-quality low-carbon steel plate cold formed. In the BS and DIN EN 10130 standards, it contains 5 other steel grades: DC03 (1.0347), DC04 (1.0338), DC05 (1.0312), DC06 (1.0873) and DC07 (1.0898), and the surface quality is divided into 2 types: DC01 -A and DC01-B. In addition, this steel is also used in electro-galvanized condition. The steel number is DC01+ZE (or 1.0330+ZE), and the standard is EN 10152.
DC01 meaning and definition:
D: (deep drawing) flat product for cold forming
C: Cold rolled
DC01: Drawing quality
DC03: Drawing quality;
DC04, DC05: special drawing quality;
DC06: Super deep drawing quality;
DC07: Super deep drawing quality.
DC01 steel equivalent material：
Material 1.0330, DC01 steel is equivalent to ASTM, ISO, European (German DIN, British BSI, French NF), Japanese JIS and Chinese GB standards (for reference).
| Product Name | Hot Dipped Galvanized Steel Coil |
| Standard | JIS G3302 1998, ASTM A653M/A924M 2004,A792/A792M, JIS G 3321, EN 10346 or at your request |
| Grade | SPCC, SPCD, SPCE, DX51D+Z, DC01, DC02, DC03, DC04, DC05, DC06, ST12, SPHC or at your request |
| Thickness | From 0.12mm to 5.0mm |
| Width | From 100mm to 1250mm |
| Zinc coating weight | 17-600gsm, double side, equal thickness |
| Spangle | big spangle, normal spangle, small spangle, zero spangle |
| Hardness | Normal (HRB70±5), Full hard (HRB90±5) |
| Surface treatment | Chemical passivating, oiled,unoiled, passivating + oils,Anti-Fingerprint ,Chromated,Skin passed, high weather resistance,etc |
| Edge | slit edge, mill edge (for splitted coil) |
| Coil ID | 508mm/610mm |
| Coil weight | 3-10 tons, at your request |
| Delivery time | within 7 days after receipt of deposit or L/C,T/T |
| Business type | Supplier and manufacturer |
DX51D galvanized sheet is a bending and forming grade galvanized sheet with a steel grade serial number of 51 and low carbon steel as the base material. The main chemical components of DX51D are as follows: C%≤0.07, Si%≤0.03, Mn%≤0.50, P%≤0.025, S%≤0.025, Alt%≥0.020.
In DX51D, D represents the bending and forming grade galvanized sheet, and 51 represents the serial number of the steel grade, which mainly uses low carbon steel as its basic material. On the dx51d, there is a layer of galvanized surface. This galvanizing method is a method that is often used in actual use. It is not only economical and affordable, but also an effective anti-corrosion method.
Customer case:
Team style:
Our advantage:
1. We can provide ex-factory price and trading company services.
2. We strictly control production quality and will not provide compensation.
3. We guarantee 24-hour response and 48-hour solution provision service.
4. We accept small batch orders before formal cooperation.
5. We provide excellent quality, reasonable prices, faster delivery and better payment terms.
6.Dx51d DC01 DC05 Galvanized Steel Coil is our hot-selling product with huge export volume.
