Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of s355j2 | 1.0577 in China. Welcome to wholesale customized s355j2 | 1.0577 at low price from our factory. If you have any enquiry about free sample and cheap products, please feel free to email us.
Non-alloy/general structural steelS355J2 | 1.0577: Properties according to DIN EN 10 025-2Steel type
| Short designation | VDA239-100 | Material number |
| S355J2 | - | 1.0577 |
S355J2 | 1.0577: Mechanical properties, transverse 1)
| Upper yield strength ReH MPa min. | Tensile strength Rm MPa | Elongation at fracture A80 % min. | Elongation at fracture A 5 % min. |
|||||
| e ≤ 16 mm | e < 3 mm | 3 mm ≤ e ≤ 16 mm | e ≤ 1 mm | 1 mm < e ≤ 1.5 mm |
1.5 mm < e ≤ 2 mm | 2 mm < e ≤ 2.5 mm |
2.5 mm < e < 3 mm | 3 mm ≤ e < 16 mm |
| 355 | 510–680 | 470–630 | 12 | 13 | 14 | 15 | 16 | 20 |
S355J2 | 1.0577: Chemical composition (heat analysis)
| Percentage by weight % max. | ||||||
| C | Si | Mn | P | S | N | Cu |
| 0.20 | 0,55 | 1.60 | 0.025 | 0.025 | - | 0.55 |
