Properties
General
| Property | Value | Comment |
|---|---|---|
|
Density
|
7.8 - 7.9 g/cm³
|
Typical for Low Carbon Steel |
Mechanical
| Property | Temperature | Value | Condition | Related Standards | Shape | Comment |
|---|---|---|---|---|---|---|
|
Elastic modulus
|
200 - 215 GPa
|
Typical for Low Carbon Steel |
||||
|
Elongation
|
17.7 %
|
Predicted Value, A200 |
||||
|
22 %
|
Predicted Value, A5 |
|||||
|
23.4 %
|
Predicted Value, A50 |
|||||
|
20 °C |
12 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 Transverse |
|
|
20 °C |
13 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 Transverse |
|
|
20 °C |
14 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 Transverse |
|
|
20 °C |
14 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 |
|
|
20 °C |
15 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 Transverse |
|
|
20 °C |
15 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 |
|
|
20 °C |
16 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 Transverse |
|
|
20 °C |
16 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 |
|
|
20 °C |
17 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 |
|
|
20 °C |
17 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
Transverse |
|
|
20 °C |
17 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
18 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
A80 |
|
|
20 °C |
18 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
Transverse |
|
|
20 °C |
18 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
19 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
Transverse |
|
|
20 °C |
20 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
Transverse |
|
|
20 °C |
20 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
21 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
22 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
Poisson's ratio
|
0.29 [-]
|
Typical for Low Carbon Steel |
||||
|
Reduction of area |
43.6 %
|
Predicted Value, Transverse |
||||
|
52.3 %
|
Predicted Value |
|||||
|
Shear modulus
|
82 GPa
|
Typical for Low Carbon Steel |
||||
|
Shear strength |
522.6 MPa
|
Predicted Value |
||||
|
Tensile strength
|
20 °C |
450 - 680 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
|
20 °C |
450 - 630 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
450 - 600 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
470 - 680 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
470 - 630 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
470 - 600 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
510 - 680 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
510 - 630 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
510 - 600 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
Yield strength
|
255.8 MPa
|
Predicted Value, RP1 |
||||
|
318.4 MPa
|
Predicted Value, RP1 Transverse |
|||||
|
346.1 MPa
|
Predicted Value, Transverse |
|||||
|
379.5 MPa
|
Predicted Value, RP05 |
|||||
|
429.7 MPa
|
Predicted Value, RP02 |
|||||
|
480.2 MPa
|
Predicted Value, RP02 Transverse |
|||||
|
482.8 MPa
|
Predicted Value, RP002 |
|||||
|
20 °C |
265 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
275 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
285 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
295 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
315 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
325 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
335 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
345 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
||
|
20 °C |
355 MPa
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
Thermal
| Property | Value | Comment |
|---|---|---|
|
Coefficient of thermal expansion
|
1.32e-05 - 1.38e-05 1/K
|
Typical for Low Carbon Steel |
|
Max service temperature |
317.8 °C
|
Predicted Value, Long |
|
500 °C
|
Typical for Carbon Steel |
|
|
Melting point
|
1480 - 1526 °C
|
Typical for Low Carbon Steel |
|
Specific heat capacity
|
465 J/(kg·K)
|
Typical for Low Carbon Steel |
|
Thermal conductivity
|
25 - 93 W/(m·K)
|
Typical for Low Carbon Steel |
Electrical
| Property | Value | Comment |
|---|---|---|
|
Electrical conductivity
|
7 S/m
|
Predicted Value |
|
Electrical resistivity
|
1.43e-07 - 1.74e-07 Ω·m
|
Typical for Carbon Steel |
Magnetic
| Property | Value | Comment |
|---|---|---|
|
Curie temperature |
770 °C
|
Typical for Low Carbon Steel |
Chemical properties
| Property | Value | Condition | Related Standards | Shape |
|---|---|---|---|---|
|
Carbon |
0.2 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
Copper |
0.55 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
Manganese |
1.6 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
Phosphorus |
0.025 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
Silicon |
0.55 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
|
Sulfur |
0.025 %
|
normalized or normalized formed (+N) |
EN 10025-2, EN 10025 |
Strip, Sheet, Flat, Rod, Wire |
