Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of dc05+ze cold-rolled low carbon steel plate in China. Welcome to wholesale customized dc05+ze cold-rolled low carbon steel plate at low price from our factory. If you have any enquiry about free sample and cheap products, please feel free to email us.
DC05 cold-rolled steel sheet can be used for frame applications in various industries and structures. Frames provide structural support, stability, and rigidity to a wide range of objects, such as buildings, vehicles, machinery, and furniture.DC05 steel exhibits good strength and load-bearing capacity, making it suitable for frame applications. It can withstand the forces and loads acting on the structure and provide the necessary structural integrity.
Cold-rolled steel, including DC05, offers excellent formability, allowing it to be shaped and fabricated into different frame designs and configurations. It can be easily cut, bent, and welded to create the desired frame structure.DC05 steel is known for its durability, ensuring the longevity and reliability of the frame. It resists deformation, bending, and warping, providing a sturdy and stable structure.DC05 steel possesses good weldability, facilitating the assembly and fabrication of frames through welding or other joining techniques. This allows for the construction of complex or customized frame structures.
- Specifications Table
|
Width
|
600-1250mm
|
|
Thickness
|
0.1mm-300mm
|
|
Length
|
1000mm-12000mm or according to customer's special request
|
|
Surface Treatment
|
According to customer requirements
|
|
Capacity
|
2000 tons /month
|
While DC05 steel offers some inherent corrosion resistance, it may require additional surface treatments or protective coatings to enhance its corrosion resistance, particularly in environments where exposure to moisture or corrosive elements is a concern.The use of DC05 cold-rolled steel sheets for frames can be found in various applications, such as building frames, vehicle chassis, equipment frames, and furniture frames. However, it's important to consider specific design requirements, load-bearing capacities, and environmental factors when selecting the appropriate steel grade and specifications for frame construction.
- Scope of Application
| DC01 | Can be used for simple forming work, for example Bending, embossing, beading and pulling. |
| DC03 | Is suitable for forming requirements like Deep drawing and difficult profiles suitable. |
| DC04 | Is suitable for high deformation requirements. |
| DC05 | Is a thermal forming grade, it is suitable for higher forming requirements. |
| DC06 | Is a grade for special deep drawing, suitable for the higher deformation requirements. |
| DC07 | This superior deep drawing quality is suitable for highest deformation requirements. |
- Mechanical Properties
|
Steel Grade |
Yield Strength (MPa) min |
Tensile Strength (MPa) min |
Elongation % min |
Old Description |
|
DC01 |
≤280 |
270-410 |
28 |
St 12-03 |
|
DC03 |
≤240 |
270-370 |
34 |
St 13-03 |
|
DC04 |
≤210 |
270-350 |
38 |
St 14-03 |
|
DC05 |
≤180 |
270-330 |
40 |
St 15-03 |
|
DC06 |
≤170 |
270-330 |
41 |
- |
|
DC07 |
≤150 |
250-310 |
44 |
- |
- Packaging and shipping
cold-rolled steel sheet
